Maxi 4000 Series Dimensions
Maxi 4000 Series Dimensions | ||||||
---|---|---|---|---|---|---|
Base Footprint | Overall Width | Overall Length | Rotation Diameter (fully extended) | Lift Height (Min - Max) | Rotation | |
28" x 28" 71 x 71 cm | 29.5" 75 cm | 79" 201 cm | 79" 201 cm | 22" - 38" 53 - 97 cm | 345° | |
Maxi 4000 Series Specifications | ||||||
Backrest Movement | Maximum Lift/Support | Electrical Requirements | Shipping Weight | Approx Weight | Seat Size | |
110° - 108° | 400 lbs. (tested to 1,600Ibs) | 120v, 60Hz, 4Amps | 408lbs. 59 kg | 339lbs. 154 kg | 22" x 18" 56 x 46 cm |
SMR® Maxi 4000 Series Color Selection
Color samples shown may vary from actual color. Additional colors are available. Call 727.471.5072 for swatches. All products are subject to improvement changes without notice.
